- Consistent Light Output
- Portable Design
- Expanded Color Temperature Range
- Boost Mode
Description
Filmmakers loved the original AL-M9. But based off of the feedback received, Aputure decided to make one that was even brighter and more versatile - the AL-MX. Designed with a metal build and SMD LED bulbs, the AL-MX is the most durable, powerful, bicolor LED light that can easily fit into your pocket.
The Brightest Ever
The AL-MX is more powerful than any other light of its size. It packs 128 SMD LED bulbs into a credit card-sized panel. With both CRI & TLCI ratings over 95, and a wide 120° beam angle that outputs 3200 lux at 0.3m, the possibilities for this light are endless.
- CRI & TLCI: 95+
- Beam Angle: 120°
- SMD LED Bulbs: 128
The AL-MX features a 5-step adjustable color temperature ranging from 2800-6500K. While most bicolor lighting fixtures range from 3200-5600K, this expanded range provides you with even more options for creative applications.
Metal Build
The AL-MX is compact and durable. Made of aircraft-grade aluminum and featuring an extremely efficient heat management system, theAL-MX is built to last for years in conditions of all kinds. In addition, with a 1/4 screw and universal cold shoe mount, you can easily install the AL-MX on cameras, light stands and so on.
Portable Design
The AL-MX inherits the M9’s legacy. Though a bit thicker in build, it has the same “credit card sized” design and weighs just 278g. In addition, with a built-in lithium rechargeable battery and USB Type-C charging port, the MX lasts an average of 1 hour at full power and 4 hours at minimum power.
Boost Mode
The AL-MX also comes with a bonus Boost option, which goes above 30% of maximum brightness when you need that extra kick. Capable of operating at 60-second intervals, boost mode gives filmmakers one more option for when "the brightest ever" still isn't enough.
Constant Light Output
AL-MX has a new form of technology that increases its reliability While many lights dim as battery life decreases, the output of the AL-MX remains the same no matter the remaining battery life, environment , temperature or any other factors.
| Light Fixture | |
|---|---|
| Color Temperature | 2800 to 6500K |
| Color Accuracy Standard | CRI 95 TLCI 95 |
| Cooling System | Passive |
| Dimming | Yes, Built-In Dimmer 20 to 100% (Stepped) |
| Photometrics | 19 fc / 200 Lux at 3.3' / 1 m* 223 fc / 2400 Lux at 0.98' / 0.3 m 82 fc / 880 Lux at 1.64' / 0.5 m |
| Panel Size | 3.7 x 2.4 x 0.9" / 9.3 x 5.98 x 2.35 cm |
| Fixture Weight | 0.62 lb / 280 g |
| App Compatible | No |
| Mounting | |
|---|---|
| Fixture Mount | 1 x 1/4"-20 Female Thread |
| Included Adapter | 1 x Ball Head Mount: Accessory Foot to 1/4"-20 Male Screw |
| Power | |
|---|---|
| Power Source | Battery (Built-In) |
| Inputs/Outputs | 1 x USB-C Power Input |
| Battery | Rechargeable Lithium-Ion Polymer, 3.7 VDC, 800 mAh |
| Runtime | 0.5- to 4-Hour Runtime |
| DC Input Power | 5 VDC at 2 A |
| Included Adapter / Cable | 1 x USB-C to USB-A Cable (3.2' / 1 m) |
