Blackmagic Design Pocket Cinema Camera 6K

BlackmagicSKU: BMD-CINECAMPOCHDEF6K
1 review

Price:
Sale price$1,995.00
Configurations

  • Active Canon EF Mount
  • 6K 6144 x 3456 up to 50 fps
  • Super 35-Sized HDR Sensor
  • Dual Native 400 & 3200 ISO to 25,600
Related Products

Description

Camera
Effective Sensor Size23.10mm x 12.99mm (Super 35)
Lens MountActive EF mount
Lens ControlIris, focus and zoom on supported lenses.
Dynamic Range13 Stops
FocusAuto focus available using compatible lenses
Dual Native ISO400 and 3200
Iris ControlIris wheel and touchscreen slider for manual iris adjustment on electronically controllable lenses, iris button for instant auto iris settings on compatible lenses.
Screen Dimensions5” 1920 x 1080
Screen TypeLCD capacitive touchscreen
Shooting Resolutions6144 x 3456 (6K) up to 50 fps
6144 x 2560 (6K 2.4:1) up to 60 fps
5744 x 3024 (5.7K 17:9) up to 60 fps
4096 x 2160 (4K DCI) up to 60 fps
3840 x 2160 (Ultra HD) up to 60 fps
3728 x 3104 (3.7K 6:5 anamorphic) up to 60 fps
2868 x 1512 (2.8K 17:9) up to 120 fps
1920 x 1080 (HD) up to 120 fps
Frame RatesMaximum sensor frame rate dependent on resolution and codec selected. Project frame rates of 23.98, 24, 25, 29.97, 30, 50, 59.94 and 60 fps supported. Off-speed frame rates up to 60 fps in 6K 2.4:1, 120 fps in 2.8K 17:9 and 1080HD.
Metadata SupportAutomatically populated lens data from electronic EF lenses. Automatic recording of camera settings and slate data such as project, scene number, take and special notes. A 3D LUT can also be embedded in metadata of Blackmagic RAW files.
ControlsTouchscreen menus on 5 inch screen. 1 x Power Switch, 1 x Record Button, 1 x Stills Button, 1 x Scroll Wheel with push integrated into handgrip, 1 x ISO, Button, 1 x White Balance, 1 x Shutter Button, 3 x software configurable Fn buttons, 1 x High Frame Rate (HFR) Button, 1 x Zoom Button, 1 x Menu Button, 1 x Play Button, 1 x Focus Button and 1 x IRIS Button.
Connectivity
Total Video InputsNone
Analog Audio Outputs1 x 3.5mm headphone jack
Total Video Outputs1 x HDMI Type A
Analog Audio Inputs1 x mini XLR analog switchable between mic with phantom power support and line level (up to +14dBu). 1 x 3.5mm Stereo Input. Can also be used for Timecode input.
Computer InterfaceUSB Type-C for external drive recording and software updates
Audio
MicIntegrated stereo microphone
Speaker1 x mono speaker built in
Standards
SD VideoNone
Ultra HD Video2160p23.98, 2160p24, 2160p25, 2160p29.97, 2160p30, 2160p50, 2160p59.94, 2160p60.
HD Video1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30, 1080p50, 1080p59.94, 1080p60.
4K DCI4KDCIp23.98, 4KDCIp24, 4KDCIp25, 4KDCIp29.97, 4KDCIp30, 4KDCIp50, 4KDCIp59.94, 4KDCIp60.
Media
Media1 x CFast card slot, 1 x SD UHS‑II card slot, 1 x USB-C 3.1 Gen 1 expansion port for external media for Blackmagic RAW and ProRes Recording.
FormatCan format media to ExFAT (Windows/Mac) or HFS+ (Mac) file systems.
Supported Codecs
CodescsBlackmagic RAW Constant Bitrate 3:1, Blackmagic RAW Constant Bitrate 5:1, Blackmagic RAW Constant Bitrate 8:1, Blackmagic RAW Constant Bitrate 12:1, Blackmagic RAW Constant Quality Q0, Blackmagic RAW Constant Quality Q5, ProRes 422 HQ QuickTime, ProRes 422 QuickTime, ProRes 422 LT QuickTime, ProRes 422 Proxy QuickTime.
Storage
Storage Type1 x CFast 2.0.
1 x SD UHS-II card.
1 x high speed USB-C expansion port for external media.
Recording FormatsBlackmagic RAW 3:1, 5:1, 8:1, 12:1, Q0 and Q5 at 6144 x 3456, 6144 x 2560, 5744 x 3024, 3728 x 3104 and 2868 x 1512 with film, extended video, video dynamic range or custom 3D LUT embedded in metadata. ProRes at 4096 x 2160, 3840 x 2160 and 1920 x 1080 with film, extended video or video dynamic range or custom 3D LUT.
Software
Software IncludedPocket Cinema Camera 6K Operating System.
Operating Systems
Mac 10.13 High Sierra, Mac 10.14 Mojave or later.
Windows 10.
Power Requirements
