Configurations
Full-Frame
Format
30.4 MP
Resolution
100-32,000
ISO Sensitivity
7 FPS
Continuous Shooting
Canon EF
Lens Mount
- 30.4 Megapixel Full-frame CMOS Sensor
- ISO 100–32,000 (expandable to 50–102,400)
- Up to 7.0 fps of continuous shooting
- 3.2" Touch Panel LCD
Description
The EOS 5D Mark IV delivers a superior brilliance and power, that all wedding, portrait, landscape, and nature photographers appreciate. With Canon's all-new 30.4 megapixel full frame sensor, superb image quality is achieved. Highly-detailed 4K video is captured with ease. With improved focus accuracy with a refined 61-point AF system and Canon's revolutionary Dual Pixel CMOS AF for quick, smooth AF for both Live View and Video shooting. Fast operation is enhanced with Canon's DIGIC 6+ Image Processor, which provides continuous shooting at up to 7.0 fps*. Built-in Wi-Fi®**, GPS*** and an easy-to-navigate touch-panel LCD allow the camera to become an extension of you. When quality matters, the EOS 5D Mark IV helps deliver results to inspire even the most discerning imagemaker.
- New 30.4 Megapixel full-frame CMOS sensor for versatile shooting in nearly any light, with ISO range 100-32000; expandable up to 50-102400 (equivalent ISO).
- 4K Motion JPEG video (DCI cinema-type 4096 x 2160) at 30p or 24p; in- camera still frame grab of 4K 8.8-Megapixel images; multiple video options include Full HD up to 60p, and HD up to 120p.
- Superb Dual Pixel CMOS AF for responsive and smooth AF during video or Live View shooting
- LCD monitor has full touch-screen interface, including selection of AF area.
- Excellent performance - up tp 7.0 fps continuous shooting speed with high-performance DIGIC 6+ Image Processor for improved speed and excellent image quality.
- 61 AF points with expanded vertical coverage with 41 cross-points, and AF possible at all 61 AF points with many lens + extender combinations effective at f/8.
- 150,000-pixel RGB+IR metering sensor helps provide precise exposure metering, helps detect flickering lights and allows for enhanced scene recognition and face detection capabilities.
- Dual Pixel RAW, in-camera Digital Lens Optimizer during shooting JPEG and Diffraction Correction technologies.
- Built-in Wi-Fi and NFC connectivity provide easy sharing to compatible smart devices, select social media sites and the Canon Connect Station CS100 device.
- Built-in GPS provides geotag information including auto time syncing with Universal Time Code (UTC) via satellites.
| Camera | |
|---|---|
| Camera Format | Full Frame |
| Lens Mount | Canon EF |
| Image Sensor | |
|---|---|
| Image Sensor Type | CMOS |
| Image Sensor Size | 36 x 24 mm |
| Total Pixels | 31.7 |
| Effective Pixels | 30.4 |
| Maximum Resolution | 6720 x 4480 |
| ISO Sensitivity | 100 to 32000 |
| Extended ISO Sensitivity | 50 to 102400 |
| Formats | |
|---|---|
| File Format | JPEG, RAW |
| Media | |
|---|---|
| Card Slots | 2 |
| Types | Slot 1: SD/SDHC/SDXC (UHS-I) Slot 2: Compact Flash (UDMA 7) |
| Autofocus | |
|---|---|
| Focus Type | Dual Pixel Autofocus and Manual Focus |
| Focus Modes | Continuous-Servo AF (C), Manual Focus (M), Single-Servo AF (S) |
| Autofocus Points | Phase Detection: 61 (41 Cross-Type) |
| Autofocus Sensitivity | -3 to +18 EV |
| Shutter | |
|---|---|
| Shutter Speed | 1/8000 to 30 Seconds Bulb Mode |
| Continuous Shooting | Up to 7 fps at 30 MP for 21 Frames (Raw) |
| Self Timer | 2/10-Second Delay |
| Interval Recording | Yes |
| Flash | |
|---|---|
| Built-in Flash | No |
| Maximum Sync Speed | 1/200 Second |
| Flash Compensation | -3 to +3 EV (1/3, 1/2 EV Steps) |
| Dedicated Flash System | eTTL |
| External Flash Connection | Hot Shoe, PC Terminal |
| Video | |
|---|---|
| File Format | MPEG-4 AVC/H.264 |
| Video Quality and Frame Rates | M-JPEG 4:2:2 8-Bit DCI 4K 4096 x 2160: 29.97p/24p/23.976p [500 Mb/s] MOV Full HD 1920 x 1080: 59.94p [180 Mb/s] Full HD 1920 x 1080: 29.97p/24p/23.976p [90 Mb/s] Full HD 1920 x 1080: 59.94p[60 Mb/s] Full HD 1920 x 1080: 29.97p/24.00p/23.976p[30 Mb/s] HD 1280 x 720: 119.88p [160 Mb/s] MP4 Full HD: 1920 x 1080: 59.94p [60 Mb/s] Full HD 1920 x 1080: 29.97p/24.00p/23.976p [30 Mb/s] Full HD 1920 x 1080: 29.97p [12 Mb/s] |
| Video Encoding | NTSC/PAL |
| Max Recording Time | 29 mins. 59 secs. |
| Monitor and Viewfinder | |
|---|---|
| Monitor Type | Fixed Touchscreen LCD |
| Monitor Size | 3.2" |
| Monitor Resolution | 1,620,000 Dot |
| Viewfinder Type | Optical (Pentaprism) |
| Viewfinder Coverage | 100% |
| Viewfinder Magnification | Approx. 0.71x |
| Connectivity | |
|---|---|
| Interface | 3.5mm Headphone, 3.5mm Microphone, Canon N3, HDMI C (Mini), USB Micro-B (USB 3.0) |
| Wireless | Wi-Fi |
| GPS | Yes |
| Power | |
|---|---|
| Battery | LP-E6N Rechargeable Lithium-Ion, 7.2 VDC, 1865 mAh |
| Battery Life | Up to 900 Shots |
| Battery Charger | LC-E6 Battery Charger |
| AC Adapter | AC Adapter Kit ACK-E6 |
| Physical | |
|---|---|
| Dimensions (W x H x D) | 5.9 x 4.6 x 3" / 150.7 x 116.4 x 75.9 mm |
| Weight | 1.76 lb / 800 g (Body Only) |
| Operating Environment | 32 to 104°F / 0 to 40°C Operating Humidity: 0 to 85% |
