Configurations
12 MP
1/1.3" CMOS Sensor
100-3200
ISO Range
4K 30P
Video
51 Mins
Max Flight Time
35.8 mph
Max Speed
- True Vertical Shooting for Online Content
- 38kph (Level 5) Wind Resistance
- Intelligent Features
- 4K HDR video
- Weighs Less than 249 g
- Beginner-Friendly, Easy-To-Fly, and Easy-To-Use
Description
Aircraft Performance | |
---|---|
Maximum Horizontal Speed | 35.79 mph / 16 m/s (S Mode) 22.37 mph / 10 m/s (N Mode) 13.42 mph / 6 m/s (C Mode) |
Maximum Ascent Speed | 11.18 mph / 5 m/s (S Mode) 6.71 mph / 3 m/s (N Mode) 4.47 mph / 2 m/s (C Mode) |
Maximum Descent Speed | 11.18 mph / 5 m/s (S Mode) 6.71 mph / 3 m/s (N Mode) 3.36 mph / 1.5 m/s (C Mode) |
Flight Ceiling Above Sea Level | With Intelligent Flight Battery: 4000 m With Intelligent Flight Battery Plus: 3000 m |
Maximum Flight Time (no wind) | 38 minutes (with Intelligent Flight Battery) 51 minutes (with Intelligent Flight Battery Plus) |
Maximum Hover Time (no wind) | 33 minutes (with Intelligent Flight Battery) 44 minutes (with Intelligent Flight Battery Plus) |
Max Flight Distance (no wind) | 18 km (with Intelligent Flight Battery and measured while flying at 43.2 kph in windless conditions) 25 km (with Intelligent Flight Battery Plus and measured while flying at 43.2 kph in windless conditions) |
Maximum Tilt Angle | 25° (C mode) 30° (N mode) 35° (S mode) |
Hovering Accuracy | Vertical: ± 0.1 m (with vision positioning) ± 0.5 m (with GNSS positioning) Horizontal: ± 0.3 m (with vision positioning) ±1.5 m (with GNSS positioning) |
Max Tilt Angle | 40° |
Max Wind Speed Resistance | 23.94 mph / 10.7 m/s (Level 5) |
Camera | |
---|---|
Sensor | 1/1.3-inch CMOS |
Effective Pixels | 12 MP |
Lens | FOV: 82.1° Format Equivalent: 24mm Aperture: f/1.7 Focus: 1 m to ∞ (with autofocus) |
ISO Range | Video: 100-3200 Still Image: 100-3200 |
Max Image Size | 4000×3000 |
Photo Format | JPEG, DNG (RAW) |
Still Photography Modes | Single Shot Interval: JPEG: 2/3/5/7/10/15/20/30/60 s JPEG + RAW: 5/7/10/15/20/30/60 s Auto Exposure Bracketing (AEB): 3 bracketed frames at 2/3 EV Bias Panorama: Sphere, 180°, Wide-angle HDR: The Single Shot mode supports outputting HDR images |
Video Resolution | 4K (3840×2160): 24/25/30fps 2.7K (2720×1530): 24/25/30/48/50/60fps FHD (1920×1080): 24/25/30/48/50/60fps HDR: Recording with the 24/25/30fps frame rate supports outputting HDR images. |
Video Format | MP4 H.264 |
Zoom Range | 4K: 2x 2.7K: 3x FHD: 4x |
Max Video Bitrate | 100 Mbps |
Supported File Formats | exFAT |
QuickShot Modes | Dronie, Helix, Rocket, Circle, Boomerang |
Color Profiles | Normal |
Supported File System | FAT32 (≤32 GB) exFAT (>32 GB) |
Supported Memory Cards | UHS-I Speed Class 3 or above is required. A list of recommended microSD cards can be found below. |
Recommended microSD Cards | SanDisk Extreme 64GB V30 A1 microSDXC SanDisk Extreme 128GB V30 A2 microSDXC SanDisk Extreme 256GB V30 A2 microSDXC SanDisk Extreme 512GB V30 A2 microSDXC Lexar 1066x 64GB V30 A2 microSDXC Lexar 1066x 128GB V30 A2 microSDXC Lexar 1066x 256GB V30 A2 microSDXC |
Flight Control System | |
---|---|
GNSS Support | GPS + GLONASS + Galileo |
Gimbal | |
---|---|
Stabilization | 3-Axis (tilt, roll, pan) |
Mechanical Range | Tilt: -135 to 80° Roll: -135 to 45° Pan: -30 to 30° |
Controllable Range | Tilt: -90° to 60° Roll: -90° to 0° |
Max Controllable Speed (tilt) | 100°/s |
Angular Vibration Range | ±0.01° |
Sensing System | |
---|---|
Sensing Type | Downward vision system |
Downward | Precise Hovering Range: 0.5-10 m |
Auxiliary Bottom Light | N/A |
Operating Environment | Downward: Diffuse reflective surface with a clear pattern and reflectivity >20% (such as cement pavement) Adequate lighting (lux >15, e.g. , normal exposure environment with indoor fluorescent lamp) |
Video Transmission | |
---|---|
Video Transmission System | DJI O2 |
Live View Quality | 720p/30fps |
Operating Frequency | 2.400-2.4835 GHz 5.725-5.850 GHz |
Transmitter Power (EIRP) | 2.4 GHz: <26 dBm (FCC), <20 dBm (CE/SRRC/MIC) 5.8 GHz: <26 dBm (FCC/SRRC), <14 dBm (CE) |
Latency (depending on environmental conditions and mobile device) | Aircraft + Remote Controller: Approx. 200 ms |
Max Download Bitrate | DJI O3: RC-N1 Remote Controller and DJI RC: 5.5 MB/s Wi-Fi 5: Max 30 MB/s |
Max Transmission Distance (unobstructed, free of interference and aligned with controller) | 2.400-2.4835 GHz; 5.725-5.850 GHz FCC: 10 km CE: 6 km SRRC: 6 km MIC: 6 km |
Signal Transmission Ranges (FCC) | Strong Interference (urban landscape): Approx. 1.5-3 km Medium Interference (suburban landscape): Approx. 3-6 km Low Interference (suburb/seaside): Approx. 6-10 km |
Antennas | 2 antennas, 1T2R |
Intelligent Flight Battery | |
---|---|
Capacity | 2453 mAh |
Weight | Approx. 2.84 oz / 80.5 g |
Voltage | 7.38 V |
Charging Voltage Limit | 8.5 V |
Battery Type | Li-ion |
Energy | 18.1 Wh |
Max Charging Power | 37 W |
Charging Time | 64 mins (with DJI 30W USB-C Charger) |
Charging Temperature | 41 to 104°F / 5 to 40°C |
Recommended Charger | DJI 30W USB-C Charger or other USB Power Delivery chargers |
Intelligent Flight Battery Plus | |
---|---|
Capacity | 3850 mAh |
Weight | Approx. 4.27 oz / 121 g |
Voltage | 7.38 V |
Charging Voltage Limit | 8.5 V |
Battery Type | Li-ion |
Energy | 28.4 Wh |
Max Charging Power | 58 W |
Charging Time | 101 mins (with DJI 30W USB-C Charger) |
Charging Temperature Range | 41 to 104°F / 5 to 40°C |
Recommended Charger | DJI 30W USB-C Charger or other USB Power Delivery chargers |
Charging Hub | |
---|---|
Compatible DJI Charger | DJI 30W USB-C Charger or other USB Power Delivery chargers |
Compatible DJI Batteries | DJI Mini 3 Pro Intelligent Flight Battery, DJI Mini 3 Pro Intelligent Flight Battery Plus |
Input | 5 V, 3 A 9 V, 3 A 12 V, 3 A |
Output (USB) | Max Voltage: 5 V, Max Current: 2 A |
Charging Type | Three batteries being charged in sequence |
DJ RC Remote Controller | |
---|---|
Model | RM330 |
Video Transmission System | DJI O3 |
Transmitter Power (EIRP) | 2.400-2.4835 GHz: <26 dBm (FCC); <20 dBm (CE/SRRC/MIC) 5.725-5.850 GHz: <26 dBm (FCC), <23 dBm (SRRC), <14 dBm (CE) |
Storage Capacity | DJI RC's storage capacity can be increased by using a microSD card. Users can store images and videos on the card and export them to a computer or other devices. |
Video Output Port | N/A |
Max Battery Life | Approx. 4 hours |
Operating Temperature | -10° to 40° C (14° to 104° F) |
Supported SD Cards | UHS-I Speed Class 3 or above is required. A list of recommended microSD cards can be found below. |
Recommended microSD Cards | SanDisk Extreme 64GB V30 A1 microSDXC SanDisk Extreme 128GB V30 A2 microSDXC SanDisk Extreme 256GB V30 A2 microSDXC SanDisk Extreme 512GB V30 A2 microSDXC Lexar 1066x 64GB V30 A2 microSDXC Lexar 1066x 128GB V30 A2 microSDXC Lexar 1066x 256GB V30 A2 microSDXC |
Wi-Fi Protocol | 802.11 a/b/g/n |
Wi-Fi Transmitter Power (EIRP) | 2.400-2.4835 GHz: <23 dBm (FCC), <20 dBm (CE/SRRC/MIC) 5.150-5.250 GHz: <23 dBm (FCC/CE/SRRC/MIC) 5.725-5.850 GHz: <23 dBm (FCC/SRRC), <14 dBm (CE) |
Bluetooth Protocol | Bluetooth 4.2 |
Bluetooth Transmitter Power (EIRP) | 2.400-2.4835 GHz: <10 dBm |
General | |
---|---|
Number of Rotors | 4 |
Operating Temperature | 32 to 104°F / 0 to 40°C |
Diagonal Size | 8.4" / 213 mm |
Overall Dimensions | 5.8 x 3.5 x 2.4" / 148.0 x 90.0 x 62.0 mm (Folded) 9.9 x 14.3 x 2.8" / 251.0 x 362.0 x 72.0 mm (Unfolded) |
Takeoff Weight | 8.78 oz / <249 g |
