Video ISO Range
Max Flight Time
The new Phantom 4 Pro V2.0 features an OcuSync HD transmission system, which supports automatic dual-frequency band switching and connects to DJI Goggles wirelessly. Like the Phantom 4 Pro and Advanced, the Phantom 4 Pro V2.0 is equipped with a 1-inch 20-megapixel sensor capable of shooting 4K/60fps video and Burst Mode stills at 14 fps. Plus, its FlightAutonomy system includes dual rear vision sensors and infrared sensing systems for a total of 5 directions of obstacle sensing and 4 directions of obstacle avoidance.
Quieter, More enjoyable flights
New aerodynamic 9455S propellers and new FOC ESC drivers offer improved noise control and sinusoidal current for increased stability. Aircraft noise has been reduced by up to 4dB* (60%) for quieter, more enjoyable flights.
New OcuSync Video Transmission
The new Phantom 4 Pro V2.0’s remote controller uses OcuSync video transmission,* which employs time-division multiplexing technology to send control signal and receive video signal simultaneously. When the controller is powered on, the OcuSync system scans for the frequency band with lowest interference and switches accordingly to maintain clear transmission. Also, thanks to OcuSync, the Phantom 4 Pro V2.0 wirelessly connects to DJI Goggles. Free from cable constraints, you can enjoy exciting FPV flight at speeds of up to 72kph (45mph) in S-mode.
The Phantom 4 Pro V2.0 remote controller utilizes the OcuSync HD video transmission system that operates on both 2.4GHz and 5.8GHz frequency bands, with a max transmission range of 7 km. Assessing environmental conditions, the aircraft chooses the best band in which to operate, helping to reduce signal interference.
Fast Switching of Frequency Point
OcuSync video transmission technology can sense environmental interference in real time. When the interference is strong, the system switches to the frequency point with the least amount of intrusion.
Camera With 1-Inch 20MP Sensor
The onboard camera has been redesigned to use a 1-inch 20-megapixel CMOS sensor. A custom engineered lens made up of eight elements is arranged in seven groups, it is the first DJI camera to use a mechanical shutter, eliminating rolling shutter distortion which can occur when taking images of fast moving subjects of when flying at high speed. In effect, it is as powerful as many traditional ground cameras. More powerful processing supports H.264 4K videos at 60fps or H.265 4K at 30fps, both with a 100Mbps bitrate. Advanced sensors and processors ensure everything is captured with more image detail and the image data needed for post-production.
Sensor size is more important to image quality than the number of pixels because a larger sensor captures more information in every pixel, improving dynamic range, signal-to-noise ratio, and low light performance. The 1-inch 20-megapixel CMOS sensor in the Phantom 4 Pro V2.0 is almost four times the size of the Phantom 4's 1/2.3in sensor. It uses larger pixels and has a maximum ISO of 12800 as well as increased contrast. It is good enough for images to be used immediately, while also capturing enough detail for advanced post-processing.
Production Optimized 4K
An enhanced video processing system allows video to be captured in cinema and production optimized DCI 4K/60 at a bitrate of 100Mpbs, enabling you to get high-resolution slow motion shots. The Phantom 4 Pro V2.0 also supposed the H.265 video codec. For a given bitrate, H.265 doubles the amount of image processing as H.265, resulting in significantly enhanced image quality. Record in the high dynamic range D-log mode to make the most of this image data for color grading.
High Resolution Lens
The resolution and contrast of a lens is critical to image quality, because only a quality lens can capture sharp, vivid photos at high resolutions. The brand new Phantom 4 Pro V2.0 camera has an aerial optimized F2.8 wide-angle lens with a 24mm equivalent focal length. It features eight elements - 2 aspherical - arranged in seven groups that fit into a smaller, more compact frame. Its images are consistently detailed with low distortion and low dispersion, ensuring that photos and videos are sharp and vivid.
5-Directions of Obstacle Sensing
FlightAutonomy is expanded with an additional set of high-resolution stereo vision sensors placed at the rear in addition to the pair placed at the front as well as infrared sensing systems places on the left and right sides. This network creates a total of 5-directions of obstacle sensing and 4-directions of obstacle avoidance, protecting the Phantom 4 Pro V2.0 from more obstacles and giving filmmakers the confidence to capture more complex images.
6-Camera Navigation System
Three sets of dual vision sensors form a 6-camera navigation system that works constantly to calculate the relative speed and distance between the aircraft and an object. Using this network of forward, rearward and downward vision sensors, the Phantom 4 Pro V2.0 is able to hover precisely in places without GPS when taking off indoors, or on balconies, or even when flying through windows with minimal pilot control. In the unlikely event that front and downward sensors are unable to operate, the aircraft can still hover in place using the rear stereo vision system. The Phantom 4 Pro V2.0 also is able to fly in complex environments at a flight speed of up to 31mph while avoiding obstacles in its path. In Narrow Sensing Mode, the Phantom 4 Pro V2.0 narrows its sensing scope enabling it to see in more detail and fly through small spaces.
What is FlightAutonomy
FlightAutonomy is an advanced aerial intelligence and flight automation platform. It is made up of a complex network of ten component groups including seven cameras. The Phantom 4 Pro V2.0 acquires a real-time view of its environment and information about the height and position of nearby obstacles to create a 3D map is can locate itself within. The IMU and compasses collect crucial flight status, speed and direction data, while redundant IMUs and compasses monitor critical data and rule out possible errors, dramatically enhancing the reliability of flight.
1080p Live View
With bi-directional perception and error-resilient technology, the Phantom 4 Pro V2.0 saves up to 30% of its bandwidth and solves common problems such as video lag and even compression artifacts within video transmission, providing crystal-clear live video at up to 1080p.
Multiple Device Connectivity
OcuSync can connect to multiple devices at the same time. It can link two remote controllers* or a remote controller and set of DJI Goggles. OcuSync can sense aircraft altitude and the relative position of aircrafts while choosing the ideal antenna combination for Goggles, the remote controller, and aircraft for optimal signal transmission.
* Linking of two remote controllers will be available in a future firmware update.
See A Different World
The Phantom 4 Pro V2.0 wirelessly connects to DJI Goggles, putting you directly in the heart of the action with dual LTPS displays that offer a high-quality 1080p live camera view with an 85° FOV. Connected via OcuSync, users can experience fast and clear FPV flight with incredibly low latency.Plus, controlling your Phantom with DJI Goggles is more intuitive than ever. Just enable Head Tracking, which allows you to move the aircraft or gimbal simply by turning your head.
Professional aerial imaging benefits from longer flight times. The Phantom 4 Pro V2.0 has a maximum flight time of 30 minutes, providing more time in the air to capture the perfect shot. The DJI GO 4 app shows battery lifetime and calculates remaining flight times according to distance traveled and more. It will give alerts when it reaches a minimum safe amount required for a safe journey back to the takeoff point. An advanced battery management system is also in place to prevent overcharging and over draining. When placed in longer term storage, batteries will discharge power to maintain good health.
