Product Information
The Leica APO-Macro-Elmarit-SL 100mm f/2.8 is an L-Mount macro and portrait lens built for close detail and longer-working-distance portraiture. Its 100mm focal length, f/2.8 aperture, and 1:0.997 maximum reproduction ratio support near-life-size subjects while retaining the reach to frame portraits from farther away.

Close-focus control
The lens focuses from 0.29m to infinity. A selectable focus limiter narrows autofocus to 1ft–1.6ft or 1.6ft–infinity, while the camera can select autofocus or manual focus operation.

Optics and construction
Its optical design uses 17 elements in 12 groups with apochromatic correction. The aluminum full-metal housing is dust- and splash-water protected, and the external elements use Leica Aqua-Dura coating. An E67 filter thread and included lens hood support the lens in use.
-
Lens hood
-
Front Cap
-
Rear Cap
| Optics | |
|---|---|
| Focal Length | 100mm |
| Maximum Aperture | f/2.8 |
| Smallest Aperture | f/22 |
| Lens Construction | 17 elements in 12 groups |
| Angle of View (Full Frame) | 22.7° diagonal / 19.6° horizontal / 13° vertical |
| Coating | Hydrophobic Aqua-Dura coating on external lens |
| Focusing | |
|---|---|
| Focus Range | 0.29m to infinity |
| Maximum Reproduction Ratio | 1:0.997 |
| Smallest Object Field | 23.9 × 35.9mm |
| Focusing | Autofocus or manual mode selected on the camera |
| Focus Limiter | 1ft–1.6ft or 1.6ft–infinity |
| Physical | |
|---|---|
| Lens Mount | Leica L bayonet fitting with contact strip |
| Filter Thread | E67 |
| Protection | Aluminum full-metal housing; dust and splash water protected |
| Length | Approx. 137mm without lens hood / 187mm with lens hood |
| Diameter | Approx. 77mm without lens hood / 82mm with lens hood |
| Weight | Approx. 801g without lens hood / 862g with lens hood |
| Identification | |
|---|---|
| Order Number | 11125 |
| Finish | Black, anodized |
