Name: Panasonic Lumix BS1H Full-Frame Box-Style Live & Cinema Camera
Brand: Panasonic
SKU: DC-BS1H
Price: 3499.99 USD
Availability: InStock

Panasonic Lumix BS1H Full-Frame Box-Style Live & Cinema Camera

Free 3-Year Extended Warranty with registration! Full details here.

Full Frame Format

24.2 MP Resolution

100 to 51,200 ISO Sensitivity

4k 60p Video

L-Mount Lens Mount

Unlimited video recording on all settings
14+ stops of V-Log/V-Gamut, Anamorphic mode
12-bit RAW output over HDMI
Full-frame sensor with Dual Native ISO
Genlock, Timecode, HDMI, 3G-SDI, Wi-Fi

The LUMIX BS1H is a versatile box-style camera that features the cinema-quality video performance of the LUMIX S1H in an easy-to-deploy profile. The BS1H contains a 24.2MP 35mm full-frame CMOS sensor with Dual Native ISO technology that captures 6K resolution at maximum ISO 51200. Maximizing the use of the pixels in the full-frame image sensor, the LUMIX BS1H is capable of 6K/24p, 5.4K/30p (3:2) or 5.9K/30p (16:9) high-resolution, smooth video recording. It also provides 10-bit 60p 4K/C4K HEVC video and 4:2:2 10-bit 4K30p in H.264 recording modes. The BS1H provides 14+ stops of dynamic range in V-Log which is as wide as those of cinema cameras and V-Log / V-Gamut compatible with popular calorimetry called “VariCam Look.”

The BS1H is capable of 4:2:2 10-bit 4K 60p/50p HDMI output. Adopting a new heat dispersion structure, it achieves unlimited video recording in a variety of recording formats, including 4:3 Anamorphic mode. Moreover, [5.9K] / [4K] / [Anamorphic (4:3) 3.5K] 12-bit RAW video data can be output over HDMI to save Apple ProRes RAW in Atomos Ninja V or save Blackmagic RAW in Blackmagic Video Assist 12G HDR. The BS1H offers an IP streaming function over Ethernet, even allowing 4K 60p (50p) video streaming in H.265.

The BS1H provides a variety of practical ports such as a USB 3.1 Type-C, a 3G-SDI (BNC) and an HDMI Type-A terminal which can be used for simultaneous output. Genlock IN and Timecode functions are also available. Power over Ethernet+ (PoE+) makes it is easy to install both physically and electrically. Control over maximum 12 sets of LUMIX BS1H cameras is available using LUMIX Tether for Multicam. Last but not least, Φ3.5 audio jack, Wi-Fi®, Bluetooth® and tethered photo shooting with LUMIX Tether for Multicam software are also available. For even higher quality sound recording, XLR microphone DMW-XLR1 (sold separately) can be used. An SDK for camera control via USB/LAN will be provided for free.

Camera
Camera Format	Full Frame
Lens Mount	Panasonic/Leica L-Mount

Image Sensor
Sensor Type	CMOS
Image Sensor Size	35.6 x 23.8 mm
Effective Pixels	24.2 Megapixel
ISO Sensitivity	100 to 51,200
Extended ISO Sensitivity	80 to 204,800

Media
Card Slots	2
Types	SD/SDHC/SDXC (UHS-II - V90 or Faster Recommended)

Shutter
Shutter Speed	1/16000 to 1/2 sec

Flash
Built-in Flash	No

Video and Audio
Video Quality and Frame Rates	H.265/H.265 Long GOP/MOV 4:2:2 10-Bit: 4096 x 2160p at 23.98/25/29.97 fps (100 to 400 Mb/s) 3840 x 2160p at 23.98/25/29.97 fps (100 to 400 Mb/s) 3328 x 2496p at 23.98/24/25/29.97 fps (150 to 400 Mb/s) 1920 x 1080p at 23.98/29.97/59.94 fps (100 to 200 Mb/s) 1920 x 1080i at 50/59.94 fps (50 to 100 MB/s) H.265/H.265 Long GOP/MOV 4:2:0 10-Bit: 5952 x 3968p at 23.98/24/25 fps (200 Mb/s) 5376 x 3584p at 25/29.97 fps (200 Mb/s) 5888 x 3312p at 23.98/25/29.97 fps (200 Mb/s) 4096 x 2160p at 23.98/24/29.97/48/50/59.94 fps (200 Mb/s) H.265/H.265 Long GOP/MOV 4:2:0 10-Bit: 1920 x 1080p at 100/119.88 fps (150 Mb/s) 1920 x 1080p at 47.95/48 fps (100 Mb/s)
Gamma Curve	Panasonic V-Gamut, Panasonic V-Log
Audio Recording	MOV: 24-Bit 48 kHz LPCM Audio MOV: 24-Bit 96 kHz LPCM Audio MP4: 24-Bit 48 kHz LPCM Audio MP4: 24-Bit 96 kHz LPCM Audio
Max Recording Time	Unlimited
External Recording	4:2:2 10-Bit via HDMI: 4096 x 2160p at 24/25/30/50/60 fps 3840 x 2160p at 24/25/30/50/60 fps 3240 x 2160p at 24/25/30/50/60 fps 2880 x 2160p at 24/25/30/50/60 fps 1920 x 1080p at 24/25/30/50/60 fps 4:2:2 8-Bit via HDMI: 4096 x 2160p at 24/25/30/50/60 fps 3840 x 2160p at 24/25/30/50/60 fps 3240 x 2160p at 24/25/30/50/60 fps 2880 x 2160p at 24/25/30/50/60 fps 1920 x 2160p at 24/25/30/50/60 fps 4:2:2 10-Bit via SDI/BNC: 1920 x 1080p at 24/25/30/50/60 fps 1920 x 1012p at 24/25/30/50/60 fps 1620 x 1080p at 24/25/30/50/60 fps 1440 x 1080p at 24/25/30/50/60 fps 4:2:2 8-Bit via SDI/BNC: 1920 x 1080p at 24/25/30/50/60 fps 1920 x 1012p at 24/25/30/50/60 fps 1620 x 1080p at 24/25/30/50/60 fps 1440 x 1080p at 24/25/30/50/60 fps
RAW Output	HDMI In Full Frame Mode: 5888 x 3312 12-Bit at 23.98/25/29.97 fps HDMI In Super35 Mode: 4128 x 2176 12-Bit at 23.98/25/29.97/50/59.94 fps 3536 x 2656 12-Bit at 23.98/25/29.97/50 fps

Monitor and Viewfinder
Monitor	None
Viewfinder	None

Connectivity
Video Connectors	1 x BNC (3G-SDI) Output 1 x HDMI (HDMI 2.0) Output
Audio Connectors	1 x 1/8" / 3.5 mm Stereo Mic/Line Level Input on Camera Body 1 x 1/8" / 3.5 mm Stereo Headphone Output on Camera Body
Built-In Microphone Type	Stereo
Interface	1 x USB Type-C Camera Interface, USB 3.1 Gen 1 Data, Control, Video Input 1 x BNC Timecode Data Input/Output 1 x BNC Genlock Data Input/Output 1 x RJ45 LAN Control, Monitor, Video Input/Output 1 x 2.5 mm LANC Control Input
Wireless Interfaces	2.4 GHz Wi-Fi 4 (802.11n), Wi-Fi (802.11b/g), Bluetooth Video Output, Control
Accessory Mount	9 x 3/8"-16 Female 1 x Hot Shoe Mount

Power
Battery	Panasonic AG-VBR Series
Power Connectors	1 x Weipu SF610/S2 (12 VDC) Input
PoE Support	PoE+ 802.3at

Physical
Dimensions (W x H x D)	3.7 x 3.7 x 3.1" / 9.3 x 9.3 x 7.8 cm
Weight	1.3 lb / 585 g
Operating Environment	14 to 104°F / -10 to 40°C Operating Humidity: 10 to 80%
