Name: Canon XA70 UHD 4K Camcorder
Brand: Canon
SKU: 5736C002
Price: 2299.0 USD
Availability: InStock

1" CMOS Sensor, DIG!C DV 6 Processor
Up to UHD 4K30 Video Recording
Integrated 15x Optical Zoom Lens
5-Axis Optical Image Stabilization

Canon XA70 UHD Camcorder
Canon PD-E1 USB Power Adapter
Canon BP-820 Lithium-Ion Battery
Lens Hood with Lens Cover
Handle
Microphone Holder
Limited 1-Year Manufacturer Warranty

The Canon XA70 Professional UHD 4K Camcorder is a compact and lightweight camera ideal for documentary or journalism-style productions. It offers UHD 4K capture, a 1" CMOS sensor, two XLR audio inputs, and a mini-HDMI output, placing it in the ENG category. This model has been updated from its predecessor, the XA55, with notable improvements including a larger 3.5mm LCD capacitive touchscreen display, a higher resolution tiltable 0.36" OLED EVF, OSD metadata recording, and a fast USB Type-C video-only output with UVC support for livestreaming to a computer.

Another notable feature is the On-Screen Display (OSD) "Time Stamp" recording, which embeds date, time, timecode, and other data into the camera files, fulfilling the requirement for legal and law enforcement videographers.

15x Optical Zoom Lens

The camera's lens optics feature an integrated 15x HD optical zoom, a nine-bladed circular iris for natural-looking highlights, and wide DR gamma support for excellent low-light recording. It incorporates professional-style features such as Dual-Pixel and Contrast autofocus, fast- and slow-motion recording, full manual control, optical and electronic image stabilization, a 3.5" touchscreen LCD, user-assignable buttons, infrared mode, and a DIG!C DV 6 image processor known for its high sensitivity and low noise. Additionally, the XA70 includes display monitoring features like zebra, color bars, and test tone, as well as a built-in neutral density filter mechanism.

XF-AVC and MP4 Recording

When it comes to recording capabilities, the camera can capture UHD 4K30 and Full HD 1080p60 footage, which can be saved to dual SD card slots in XF-AVC and MP4 formats. The camera also offers simultaneous recording to both cards and automatic switching between them. Through its mini-HDMI port, it can output up to 1920 x 1080p 10-bit 4:2:2 video at 59.94 fps. On the audio side, the XA70 supports up to four channels of LPCM audio with manual or automatic recording levels, and it provides two XLR inputs with phantom power, a 3.5mm stereo mini input, a built-in stereo microphone, a headphone jack, and a 2.5mm LANC input for control.

UVC Livestreaming

The XA70 also offers UVC livestreaming functionality, allowing you to stream HD video directly from the camera to a Windows or macOS computer using UVC1. However, audio output through USB is not supported.

Imaging
Sensor Resolution	Actual: 13.4 Megapixel (4268 x 3148) Effective: 8.29 Megapixel (3840 x 2160)
Image Sensor	1"-Type CMOS
Image Stabilization	Optical
Built-In ND Filter	Mechanical Filter Wheel with 2-Stop (1/4), 4-Stop (1/16), 6-Stop (1/64) ND Filters
Capture Type	Stills & Video

Exposure Control
Shutter Type	Not Specified by Manufacturer
Shutter Speed	1/2000 to 1 Second
Minimum Illumination	1.7 Lux at 1/30 Shutter Speed 0.1 Lux at 1/2 Shutter Speed
White Balance	2000 to 15,000K

Lens
Focal Length	8.3 to 124.5mm (35mm Equivalent: 25.5 to 382.5mm)
Optical Zoom Ratio	15x
Max Digital Zoom	40x
Maximum Aperture	f/2.8 to 4.5
Minimum Focus Distance	Wide: 0.4" / 1.0 cm Entire Zoom Range: 23.6" / 60.0 cm
Filter Size	58 mm
Focus Control	Autofocus Manual Focus

Video Capture
Internal Recording Modes	H.264/MP4 4:2:0 8-Bit 3840 x 2160 at 23.98/24.00/29.97 fps 1920 x 1080p at 23.98/24.00/29.97/59.94 fps [35 to 45 Mb/s] 1280 x 720 at 59.94 fps [8 Mb/s] XF-AVC 4:2:0 8-Bit 3840 x 2160 at 23.98/24.00/29.97 fps 1920 x 1080p at 23.98/24.00/29.97/59.94 fps
External Recording Modes	4:2:2 8-Bit via HDMI 1920 x 1080p at 25/50 fps 1280 x 720 at 50 fps
Fast-/Slow-Motion Support	Yes
Broadcast Output	NTSC
Built-In Microphone Type	Stereo
Audio Recording	MP4: 2-Channel 16-Bit AAC Audio MP4: 4-Channel 16-Bit LPCM Audio XAVC: 4-Channel 24-Bit LPCM Audio

Still Image Capture
Image File Format	JPEG

Interface
Media/Memory Card Slot	Dual Slot: SD/SDHC/SDXC (UHS-I)
Video I/O	1 x Mini-HDMI 2.0 Output
Audio I/O	2 x XLR 3-Pin Mic/Line (+48 V Phantom Power) Input 1 x 1/8" / 3.5 mm TRS Stereo Headphone Input 1 x 1/8" / 3.5 mm TRS Stereo Microphone Input
Power I/O	1 x USB-C Input
Other I/O	1 x USB-C Output 1 x 2.5 mm Sub-Mini (LANC) Control Input

Monitor
Size	3.5"
Resolution	2,760,000 Dot
Display Type	Articulating Touchscreen LCD

Viewfinder
Type	Built-In Electronic (LCD)
Size	0.36"
Resolution	1,770,000 Dot
Diopter Adjustment	-5.5 to +2

Environmental
Operating Temperature	32 to 72°F / 0 to 40°C (Recommended)
Storage Temperature	23 to 113°F / -5 to 45°C
Operating Humidity	85%
Storage Humidity	60%

General
Battery Type	Canon BP-8 Series
Power Consumption	5.3 W
Tripod Mounting Thread	1/4"-20 Female
Accessory Mount	1 x Cold Shoe Mount
Dimensions (W x H x D)	8.4 x 4.3 x 3.6" / 21.3 x 10.9 x 9.1 cm
Weight	2.2 lb / 985 g (Body Only) 3.2 lb / 1460 g (With Battery, Handle, Recording Media)
